4 Lift the retaining ring out of the shaving unit.
5 Remove the shaving heads and place new ones
in the shaving unit.
Make sure the two wings of the shaving heads t
exactly into the recesses.
6 Place the retaining ring back onto the shaving
unit (1). To reattach the retaining ring, turn it
against the direction of the arrows indicated in
and on the retaining ring (2).
Make sure the retaining ring is xed properly. The four
wings of the retaining ring have to be located exactly
under the recesses of the shaving unit.
7 Reattach the shaving unit to the shaving
attachment.
If the shaving unit does not close smoothly, check if you
have positioned the shaving heads properly and if the
retaining rings are xed properly.
ENGLISH
24
