Display Functions in normal operation
The controller has an LC display and an acoustic warning signal.
In normal operation, the controller shows the state of charge of the battery and the solar panel
activity. Any change of the state of charge (SOC) to a lower status is additionally signaled
acoustically.
Symbol display
Symbol Status and function Symbol Status and function
System OK Load OK
System not OK (Error or empty) Load current flowing
26
LC-Display
buttons:
ESC, DOWN, UP, SET
