I/O mapping
107967_en_01 PHOENIX CONTACT 2/12
Table of contents
1 Description..................................................................................................................................1
2 Safety notes................................................................................................................................2
3 Installation ..................................................................................................................................2
4 Schematic view...........................................................................................................................3
5 Setting the thumbwheel ..............................................................................................................3
6 Configuring the SHDSL extender................................................................................................4
7 Increasing timeout for the front modules ...................................................................................10
2Safety notes
This application note does not replace the device-specific
documents. Please follow the safety notes in the associated
packing slips for the devices.
3 Installation
Figure 1 Installing the DIN rail connector
For the schematic view, please refer to the next page.
Mount the RS-485 front module and the I/O extension
module onto the DIN rail connector as described in the
packing slip.
The DIN rail connector is used to bridge the power supply
and communication. A separate power supply or data cable
is therefore not required for the I/O extension module.
Install the SHDSL extender as described in the packing
slip.
WARNING: Explosion hazard when used in
potentially explosive areas
Please follow the safety notes in the associated
packing slips for installation in Zone 2.
In potentially explosive areas, only snap the de-
vice on or off the DIN rail connector and connect
or disconnect cables when power is disconnect-
ed.
The switches of the device that can be accessed
may only be actuated when the power supply to
the device is disconnected.
