I/O mapping
107967_en_01 PHOENIX CONTACT 5/12
• Create a new project file. This file can be used as a
backup file in case you need to replace an SHDSL
extender.
• Select “Point-to-point wizard” to set up a point-to-point
connection.
Figure 5 Point-to-point wizard
• In step 2, enter a name for the SHDSL extender.
Figure 6 Assigning the device name
