Phoenix Model K8B - Installing Major Airframe Components; Installing Horizontal Stabilizer; Installing Elevator; Installing Rudder

5
12
13
2. Attach the wing to the fuselage as picture.
1. Remove the covering.
4. Secure the horizontal onto the fuselage.
3. Test the position of the elevator and adjust it as
shown.
14
Plastic Screw
INSTALLING THE RUDDER
1. Repeat step #1 - #5 from installing the aileron
to install the rudder.
17
16
Glue the hinges
by C.A glue
INSTALLING THE HORIZONTAL STABILIZER
INSTALLING THE elevator
- Repeat step #1 - #5 from installing the aileron
to install the elevator.
15
18
2. Remove the covering from the fuselage.
