Phoenix KS10002 - Page 6

6
3
Fig 3a
Fig 4
Fix the Locking Casters (D11) to the Left Front Leg (D2) and Left Rear Leg (D1) as fig 3a.
Fix the Casters (D9) to the Right Front Leg (D4) and Right Rear Leg (D3) as fig 3b.
4
Fix the Cart Side Panel (D6) on the Left Front Leg (D2) and Left Rear Leg (D1) using M6*12 bolts (E1) as fig 4.
Fix the bolts tightly by the screwdriver.
Fig 3b
