9. SPECIFICATION
SPECIFICATIONS
Model S35010 S35015
Dimension (L x W x H mm)
(L x W x H inch)
37.8” x 18.9” x 34.6”
960 x 480 x 880 mm
87.6 lb / 39.8 kg Weight W/I battery
W/O battery
66 lb / 30 kg
Battery 12V 12 Ah x 2
Charger 24V 2A
Front Tire 200 x 50 solid
Rear Tire 200 x 50 solid
Driving System Direct rear wheels (with differential gear)
Brake System Electromagnetic brake
Control Method By speed control lever
Top Speed 4 mph / 6.4km/hr
Climbing angle 6- 8
Cruising range (see note) 10 miles / 16 km
Max. User weight 250 lbs / 115 kg
Remark: The manufacturer reserves the right to modify the specification if necessary. The
final specification is subject to the individual scooter you purchase from your dealer.
Note:
Maximum driving distance is based on an ambient temperature of 68°F, a 165 lb. driver
and a brand new fully charged battery by a constant driving speed at 3.5 mph with 70%
battery power discharged.
