PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
14
MAY 2018
(6) HEATING - HEATERS (OPTIONAL)
1 TANK IMMERSION HEATER: 110 VOLTS/2000 WATTS EACH
1 AIR HEATER: 12 VOLTS DC/ENGINE COOLING SYSTEM
110 VOLT HEATER IS CONNECTED TO (1) CONNECTION POINT– A 20 AMP FEMALE INLET
LOCATED ON THE DRIVERS SIDE FRONT PANEL. THE AIR HEATER IS SWITCHED FROM
THE MODULE CONTROL PANEL
110 VOLT
POWER
RECEPTACLE
FOR HEATER(S)
CHAPTER 1
GENERAL INFORMATION AND OPERATION INSTRUCTIONS
SECTION 1 - SPECIFICATIONS AND CAPABILITIES
