PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
13
MAY 2018
CHAPTER 1
GENERAL INFORMATION AND OPERATION INSTRUCTIONS
SECTION 1 - SPECIFICATIONS AND CAPABILITIES
LAVATORY SERVICE MODULE
(1) TANKS: WASTE TANK - CAPACITY: (TL600) 360 U.S. GALLONS
(TL700) 400 U.S. GALLONS
FLUSH TANK - CAPACITY (TL600) 240 U.S. GALLONS
(TL700)) 300 U.S. GALLONS
(2) PUMPS - FLUID PUMP - 1” INCH INLET/1” OUTLET BRONZE CONSTRUCTION
POSITIVE DISPLACEMENT GEAR PUMP - CAPABLE OF 23 GPM @ 60 P.S.I.
(3) SERVICING HEIGHTS - THIS VEHICLE IS CAPABLE OF SERVICING ALL AIRCRAFT
LAVATORIES WITH A MAXIMUM CONNECTION HEIGHT OF 10 FEET AND FITTED WITH
COMMERCIAL AIRCRAFT FITTINGS.
(4) CONTROLS - CONTROLS FOR PUMP AND WORK LIGHTS ARE LOCATED AT THE REAR
WORK STATION.
(5) LIGHTING - AIRCRAFT SPOT LIGHT - 1 ON TOP DECK 1 CONTROL PANEL FLOOD LIGHT.
