PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
30
MAY 2018
CHAPTER 1
SECTION 3 - OPERATION
AIRCRAFT SERVICING WITH PLATFORM LIFT
(1) CAREFULLY POSITION UNIT TO AIRCRAFT SO THAT THE WASTE AND FLUID
HOSES CAN BE CONNECTED TO THE AIRCRAFT WITHOUT ANY SHARP KINKS
OR BENDS.
(2) SET TRANSMISSION IN PARK POSITION, SET EMERGENCY HAND BRAKE BY
PULLING UP ON HANDLE OR SETTING WITH FOOT, ALLOW ENGINE TO IDLE.
(3) ACTIVATE ENGINE IDLE-UP FUNCTION. IDLE-UP MUST BE ACTIVATED BEFORE
USING LIFT AND/OR PUMPING FUNCTIONS. (ENGINE MUST BE WARMED UP ON
FORD. ISUZU WITH OPTIONAL SMART TRUCK SYSTEM AUTOMATICALLY IDLES
UP WHEN HYDRAULIC FUNCTIONS ARE ACTIVATED).
FORD: 1. FLIP AUX 1 SWITCH UP.
ISUZU:
1. PUSH CRUISE CONTROL BUTTON TO TURN ON (GREEN LIGHT ON
BUTTON IS ILLUMINATED).
2. ROTATE CRUISE CONTROL RING SWITCH ON TURN SIGNAL LEVER TO
SET AND HOLD FOR THREE (3) SECONDS UNTIL CRUISE CONTROL
LIGHT REMAINS ILLUMINATED ON INSTRUMENT PANEL. ENGINE
WILL NOW IDLE-UP AT PRESET 1100 RPM.
3. NOTE: THE IDLE-UP FUNCTION WILL STOP IF ANY OF THE
FOLLOWING OCCURS: THE ACCELERATOR PEDAL IS PRESSED, THE
BRAKE PEDAL IS PRESSED, THE GEAR SELECTOR IS MOVED OUT OF
PARK, THE EMERGENCY BRAKE IS RELEASED.
WARNING:
LAVATORY FLUIDS MUST BE PROPERLY DISSOLVED OR DILUTED
ACCORDING TO MANUFACTURER’S INSTRUCTIONS. FAILURE TO
DO SAY MAY RESULT IN DAMAGED PUMP AND/OR FLOW METER
PARTS.
NOTE:
REFER TO YOUR ORGANIZATIONS PROCEDURE FOR RINSING AND
CHARGING AIRCRAFT WASTE TANK.
ALWAYS FOLLOW YOUR ORGANIZATION’S PROCEDURE FOR
ALIGNMENT AND APPROACH OF AIRCRAFT!
AN EMERGENCY STOP SWITCH IS PROVIDED IN CASE OF EMERGENCY.
PUSHING THE RED EMERGENCY STOP BUTTON WILL KILL VEHICLE
ENGINE AND STOP ALL LIFT AND PUMP FUNCTIONS.
