PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
36
MAY 2018
CHAPTER 1
SECTION 3 - OPERATION
(2) 12 VOLT AIR HEATER
(A) DURING SUB FREEZING CONDITIONS AND AFTER THE VEHICLE ENGINE
TEMPERATURE HAS RISEN, THE AIR HEATER INSIDE THE LAVATORY MODULE
WILL SUPPLY WARM AIR TO THE PLUMBING CIRCUIT. A TOGGLE SWITCH
LOCATED AT THE REAR OF THE MODULE ON THE METER BOX CONTROLS THE
HEATER.
FUEL SERVICING
THE FUEL TANK ON THIS VEHICLE IS LOCATED IN THE AFT OF THE CHASSIS. THE FUEL
FILL IS LOCATED ON THE DRIVER SIDE REAR OF MODULE JUST BEHIND THE REAR
WHEEL.
(1) POSITION VEHICLE SO THAT THE FILL PORT IS ON THE SIDE OF THE FUEL PUMP.
(2) PLACE TRANSMISSION SELECTOR IN PARK POSITION AND SET EMERGENCY
BRAKE.
(3) TURN ENGINE OFF.
(4) REMOVE CAP AND BEGIN FILLING.
(5) FILL TANK TO DESIRED LEVEL.
(6) REPLACE CAP WHEN FINISHED.
ISUZU MODEL: FORD MODEL:
