Phonak DigiMaster 5000 - User Manual

1
Installation instructions
Dynamic SoundField
V4.00/2011-09/visu’l/© Phonak AG/All rights reserved/page 1/7
Follow these installation instructions carefully to make sure your Dynamic SoundField system is properly installed.
Dispose of the packaging material as per local regulations.
The following materials are included (if any are missing, contact your local Phonak dealer):
DigiMaster 5000/7000 package
B DA KC
Wall support (1x)
B
Array fixation (1x)
C
Power adapter and power cable
(delivered in separate packages)
OPTION
DigiMaster
loudspeaker (1x)
A
Torx-screws (4x)
Anchors (4x)
Clamps (2x)
D
K
Torx screwdriver T20 (1x)
and hex wrench 5 (1x)
and hex wrench 6 (1x)
Hex-screws (2x)
