Phonak Roger BaseStation - Page 11

Quick start guide Digital Wireless Earpiece
11
50 - 70 m
15 - 40 m
5 Roger Repeater
5.1 Description
The Roger Repeater makes it possible to extend the coverage of the Roger BaseStation transmitter. Several repeaters
can either be linked up or mounted in a star configuration in relation to the BaseStation.
Due to better reception, the range between the BaseStation and a repeater or between two repeaters will be from
50 m to 70 m. The range to an earpiece is from 15 to 40 m.
5.2 Utilization
To Connect a repeater to the BaseStation, proceed as for an earpiece by pushing the Connect button on the BaseStation,
with the repeater at a maximum distance of 10 cm.
