2.2.4 Connect a Roger Earpiece
 Place a Roger Earpiece less than 10 cm from the antenna;
 Push the Connect button;
 The LED should light up in green for 2 seconds.
N.B.:
 Only one earpiece can be connected at a time. Once connected a new earpiece can be added to the network.
 An unlimited number of earpieces can be connected.
 The earpiece remains connected even after a battery change.
 After connect, check the volume in the earpiece and set it with the potentiometer of the transmitter.
 The volume setting can be altered in a range from -14 dB to +12 dB in steps of 2 dB.
 All the earpieces connected with the transmitter will be affected by the volume setting.
 To set the volume individually on each earpiece, use the Roger Touchscreen Mic (see below).
 To disconnect the BaseStation from all the connected earpieces, push the NewNet button on the back for more
than 7 seconds; the corresponding LED will light up in green for 2 seconds.
