Phonak Roger Touchscreen User Manual

Connecting to Computers/Tablets
1. Plug one end of supplied 3.5 mm/ 1/8 “ cable into the
multimedia device’s audio out (i.e. headphone jack).
2. Plug the other end into the Roger Touchscreen
Mic’s 3.5 mm/ 1/8 “ audio jack.
3. Select “input” from the pop up menu on the Touchscreen
4. Select “Headphones” from the pop up
menu on your computer. Figure 1
5. Control volume by clicking on the speaker icon on the
bottom right corner of your computer screen. Figure 2
Figure 1
Figure 2

Phonak Roger Touchscreen Specifications

General

Power Source	Rechargeable battery
Compatibility	Roger receivers
Microphone	Yes
Operating Range	20 meters
Display	Touchscreen
Charging Method	Micro-USB
Water Resistance	No
