Phonic Ear PE 600E - Emitter: PE 600 E

2
emitter: PE 600E (cont’d)
3 input level detector
(Channel A/Left) Green
4 wall mounting hole
1 mounting support
5 mic in
(Channel B/Right)
2 input level detector
(Channel B/Right) Red
7 audio in
(Channel B/Right) Yellow
10 sync in
(Channel A/Left) Red
9 sync in
(Channel B/Right) Red
6 mic in
(Channel A/Left)
8 sync out
(Channel B/Right) White
11 sync out
(Channel A/Left) White
12 audio in
(Channel A/Left) Yellow
13 DC in
3556 SS600 User Guide 7/28/03 2:55 PM Page 8
