Phonic AM440W - Specifications

5AM440/AM440D/AM440W
English
SPECIFICATIONS
Model Name AM 440 AM 440D AM 440W
Inputs
Total Channels 8 8 8
Balanced Mono Mic / Line Channel 4 4 4
Balanced Stereo Line Channel 4 4 4
2T Input Stereo RCA Stereo RCA Stereo RCA
Outputs
Main L/R Stereo 2 x 1/4” TRS, Bal. 2 x 1/4” TRS, Bal. 2 x 1/4” TRS, Bal.
Rec Out Stereo RCA Stereo RCA Stereo RCA
CTRL RM L/R 2 x 1/4” TS 2 x 1/4” TS 2 x 1/4” TS
Phones 1 1 1
Channel Strips 6 6 6
Efx Send 1 2 2
Pan/Balance Control Yes Yes Yes
Volume Controls Rotary Rotary Rotary
Inserts N/A 4 4
Master Section
Phones Level Control Yes Yes Yes
Main L/R Level Control Main L/R, 60mm fader Main L/R, 60mm fader Main L/R, 60mm fader
Level Meter 2 x 4-segment 2 x 4-segment 2 x 4-segment
Phantom Power Supply +48VDC +48VDC +48VDC
Bluetooth Audio DAC
Bluetooth 3.0
+ EDR compliant> 90dB SNR
Frequency Response
(Mic input to any output)
20Hz ~ 60KHz +0/-1 dB +0/-1 dB +0/-1 dB
20Hz ~ 100KHz +0/-3 dB +0/-3 dB +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main L/R outputs)
Channel fader down, other
channels at unity
<-90 dB <-90 dB <-90 dB
Noise (20Hz~20KHz; measured at main output, Channels 1-4 unit gain;EQ at; all channels on main mix; channels 1/3 as far left as
possible, channels 2/4 as far right as possible.
Reference=+6dBu)
Master @ unity, channel fader
down
-86.5 dBu -86.5 dBu -86.5 dBu
Master @ unity, channel fader @
unity
-84 dBu -84 dBu -84 dBu
S/N ratio, ref to +4 >90 dB >90 dB >90 dB
Model Name AM 440 AM 440D AM 440D
Microphone Preamp E.I.N. (150 <-129.5 dBm <-129.5 dBm <-129.5 dBm
ohms terminated, max gain)
THD (Any output, 1KHz @ +14dBu, <0.005% <0.005% <0.005%
20Hz to 20KHz, channel inputs)
CMRR (1 KHz @ -60dBu, Gain at
maximum)
80 dB 80 dB 80 dB
