page 17
PHONIC CORPORATION POWERPOD 745 / 865 / 885 User's Manual
THD
Power output, 1KHz, 20Hz to
20KHz
@110 watts, 4 ohms <0.5% @150 watts, 4 ohms <0.5% @200 watts, 4 ohms <0.5%
Any output, 1KHz @ +14dBu,
20Hz to 20KHz, channel inputs
<0.3% <0.3% <0.3%
CMRR (1 KHz @ -60dBu, Gain at
maximum)
80 dB 80 dB 80 dB
Crosstalk (1KHz @ 0dBu, 20Hz
to 20KHz bandwidth, channel
in to main L/R outputs)
Channel fader down, other
channels at unity
<-63 dB <-63 dB <-63 dB
Channel muted, other channels
at unity
<-64 dB <-64 dB <-64 dB
Frequency Response
(Mic input to output)
20Hz ~ 20KHz, line level o/p @
+4dBu into 600 ohms
+0/-2 dB +0/-2 dB +0/-2 dB
20Hz ~ 20KHz, power amp o/p 1
watt into 8 ohms
+0/-2 dB +0/-2 dB +0/-2 dB
Maximum Level
Mic preamp input +10 dBu +10 dBu +10 dBu
All other inputs +22 dBu +22 dBu +22 dBu
Unbalanced output +22 dBu +22 dBu +22 dBu
Impedance
Lo-Z input (Mic in) 2.2K ohms 2.2K ohms 2.2K ohms
Hi-Z input (Line in) 5K ohms 5K ohms 5K ohms
Super Hi-Z (Line in) 470K ohms 470K ohms 470K ohms
All other input >10K ohms >10K ohms >10K ohms
RCA 2T output 1.2K ohms 1.2K ohms 1.2K ohms
All other outputs 560 ohms 560 ohms 560 ohms
Equalization 3-band, ±15 dB 3-band, ±15 dB 3-band, ±15 dB
Low EQ 80 Hz 80 Hz 80 Hz
Mid EQ on channel 1 & 2 100-8K Hz sweepable 100-8K Hz sweepable 100-8K Hz sweepable
Mid EQ on channel 3 and above 2.5 kHz 2.5 kHz 2.5 kHz
Hi EQ 12 kHz 12 kHz 12 kHz
Foot switch Digital effect mute: ON/OFF Digital effect mute: ON/OFF;
tap delay
Digital effect mute: ON/OFF;
tap delay
Microphone Preamp E.I.N.
150 ohms terminated, max gain <-122 dBm <-122 dBm <-122 dBm
Power Consumption
(Average Maximum)
220 Watts 300 Watts 400 Watts
Power Requirement
(depends on regions)
100-120VAC, 220-240VAC,
50/60 Hz
100-120VAC, 220-240VAC,
50/60 Hz
100-120VAC, 220-240VAC,
50/60 Hz
Net Weight 10.5 kg (23.1 lbs) 11 kg (24.2 lbs) 12 kg (26.4 lbs)
Dimensions (W x H x D) 474x348x340mm
(19”x14”x13”)
474x348x340mm
(19”x14”x13”)
474x348x340mm
(19”x14”x13”)
