PHONIC CORPORATION
Page 19
XP3000/3000(B) S ERVICE MANUAL
POWER SUPPLY PCB-PART LIST
POWER SUPPLY PCB-PART LIST
Ref. Phonic Part No. Specifications
VR1.VR2 023-50230-040-0 D.ROT/VR 5KA 20MM P
Ref. Phonic Part No. Specifications
D101.102 090-10000-000-0 B/DIODE PB154
LED101.102.301A.301B 100-00010-030-0 LED BL-B5141 RED
LED305A.305B 100-00040-000-0 LED 204YD YLW
LED302A.302B.303A.303B.304A.
304B
100-00050-000-0 LED BL-B2141 GRN
SW5.6 210-00204-050-0 ROT/SW
BTSR16H-14N-S25
JK2A.3A 211-01602-560-0 6D4/J YLJ-6405-300
(NUT&WASHER)
JK2.3 211-03300-160-0 XLR/J SKCA229-1K3F2
JK4.5 211-03400-021-0 SPEAKON/J SVP563S-CH
CN4.5 211-10031-170-0 3P WAFER/S 2532-03
(PITCH:2.5MM)
SPEAKON 212-10010-680-0 1P WAFER/P 80MM
UL1015#14 BLK
SPEAKON 212-10010-690-0 1P WAFER/P 80MM BWN
SPEAKON 212-10010-720-0 1P WAFER/P 80MM
UL1015#14 RED
SPEAKON 212-10010-730-0 1P WAFER/P 80MM
UL1015#14 ORANGE
JP10A 212-10061-310-0 6P WAFER/P 170MM
UL1007#24 PH=2.5MM
JP10B 212-10061-320-0 6P WAFER/P 220MM
UL1007#24 PH=2.5MM
JP6.7 212-10061-330-0 6P WAFER/P 220MM
UL1007#24
JP1 212-11214-000-0 IC/P 120MM
JP2 212-11220-000-0 IC/P 120MM PIII2000/3000
PH=2.54MM
615-20104-620-0 LED HOLDER 3LED-3
