Phottix Ares II - Transmitter Parts; Component Identification

4
Parts
Transmitter
1. Power button
2. LCD display
3. Settings button
4. Group selection buttons (From
left to right is A,B,C,D)
5. Test button
6. Selection button up
7. OK/conrm button
8. Selection button down
9. LED status light
10. Lanyard attachment
11. Battery compartment cover
12. Locking ring
13. Hot shoe contact
14. Hot shoe
15. Locking Pin
1 5
2
6
3
7
4
8
9
10
11
12
13
15
14
