to hold the body of the Battery Pack.
2. Push it to the right until the lock engages with a
click, this ensures it is locked. (See picture 2)
Note: when the Li-ion cell is properly assembled onto
the body of the Battery Pack, the Output Indicator
(orange), the Battery Level Indicators (green) and the
USB indicator (red) will all light up and ash 3 times.
picture 2
To charge the battery pack
Use an original Phottix AC Charging Unit only.
1. Insert the output charging connector of the AC
Charging Unit into the charging port on the Battery
Pack.
2. Connect the AC power cord of the AC Charging Unit
to the mains power supply. (See picture 3)
picture 3
