Technical Specs
Frequency: 2.4 GHz
Distance: 150+m
Channels: 4 channels
Groups: 4 groups – A, B, C, D
Batteries: 2 x AAA batteries (Transmitter and
Receiver) 5V DC (external power port)
Max sync speed: 1/250 sec*
Output: Hot shoe, 3.5 mm, 2.5 mm ports (receiver)
Input: 3.5mm PC input port (transmitter)
Attachment: 1/4 tripod lug, cold shoe (Receiver)
Input voltage: 2.5-3.2V
Minimum response time: 350us (For Canon),
800us (For Nikon)
Top ports: TTL port on the top of transmitter
C/F port voltage handling: 5V
Flash port voltage handling: 6V (trans-
mitter) 300V (receiver)
Body dimensions: 87(L)*40(W)*38(H)mm
(transmitter), 85(L)*40(W)*36(H)mm (receiver)
Antenna: built-in PCB antenna
Weight: 60g (transmitter); 49g (receiver)
Operating temperature: -15 +65
O
C
Storage temperature: -30 +85
O
C
