Phottix Strato TTL - Technical Specifications; Radio Specifications; Electrical and Performance Specs; Physical and Connectivity Specs

17
INSTRUCTION MANUAL
EN
Technical Specications
：
Transmitting power : ≤10dBm
Distance
：
100m+
Frequency: 2.4GHz
Channel: 4 channels
Input voltage
：
2.2V-3.2V
Flash port voltage handling: Transmitter 6V;
Receiver ≤300V
Batteries: 2xAA alkaline batteries or
rechargeable batteries (Transmitter and
Receiver); 5V DC on Receiver (external power
port)
Max sync speed: 1/8000s
Output: hot shoe, 3.5mm (Receiver)
Input: USB port (transmitter and Receiver)
Attachment: 1/4” tripod lug, cold shoe
(Receiver)
Weight: Transmitter 74g; Receiver 72g----
without batteries
Body dimension: Transmitter L 92.5 * W 47.8 *
H 45.5 mm; Receiver L 93.3 * W 46.7 * H 45.4 mm
Antenna
：
Built-in PCB antenna
Operating temperature: 0
℃～
+50
℃
Operating humidity: 35%
～
95%RH
