INSTALLATION TYPE C
Single factory horn with a single wire plug.
PARTS NEEDED: Two insulated 1/4" female blade connectors, approximately
3ft of 16AWG insulated wire, one splice connector
1.Cut off the factory plug and splice two lengths of wire to the factory positive (+)
horn wire. Make sure the lengths of wire will reach the mounting locations
of the PIAA Sports Horns.
2.Crimp an insulated 1/4” female blade connector to the end of each wire
that was added.
3.Plug the new 1/4” female blade connectors to the top terminals
on the PIAA Sports Horn.
4.Plug the included ground wires to bottom terminals on the PIAA Sports Horn
and ground them to a good chasse ground(-).
INSTALLATION (Cont'd)
Factory Horn
PIAA Sports Horns
