03_08
03_09
Spark plug dismantlement (03_08, 03_09)
Proceed as follows:
1. Remove the access cover over the spark plug on the right-hand side of the scooter
and reach into the spark plug with your hand;
2. Disconnect spark plug HV wire cap «A» ;
3. Unscrew the spark plug using the spark plug wrench supplied;
4. When refitting, place the spark plug into the hole at the required angle and tighten
by hand until it is finger tight;
5. Use the wrench only for final tightening of the spark plug;
6. Place hood "A" fully over the spark plug.
N.B.
THE USE OF SPARK PLUGS OTHER THAN THE INDICATED TYPE OR OF
SHIELDLESS SPARK PLUG CAPS CAN CAUSE ELECTRICAL SYSTEM FAIL-
URES.
WARNING
THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD. CHECK
THE SPARK PLUG AS INDICATED IN THE SCHEDULED MAINTENANCE TABLE.
USING NON-COMPLYING ELECTRONIC CENTRAL UNITS AND ELECTRONIC
IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED MAY SERI-
OUSLY DAMAGE THE ENGINE. IF THE SPARK PLUG IS REMOVED AFTER A
FLOODED ENGINE (EXCESSIVE FUEL EXPULSION IN THE «SAFE RIDING»
SECTION), KEEP THE TUBE CONNECTED TO THE SPARK PLUG AND THE
LATTER IN CONTACT WITH A GROUND POINT FAR FROM THE SPARK PLUG
HOLE ITSELF IN ORDER TO AVOID THE EXPELLED FUEL FROM CATCHING
FIRE.
Characteristic
Spark plug
46
