FUSES
Fuse no. 1 Threshold of operation: 30 A
Location: battery compartment
Protected circuits: recharge the
battery and fuses 8,9,10,11
Fuse no. 2 Threshold of operation: 7.5A
Location: battery compartment
Protected circuits: direct battery-
powered fuel system for electric
fan
Fuse no. 3 Threshold of operation: 20A
Location: battery compartment
Protected circuits: direct battery-
powered fuel system for parking
control ECU
Fuse no. 4 Threshold of operation: 10 A
Location: battery compartment
Protected circuits: direct battery-
powered fuel system for headlight
and 12 fuses
Fuse No. 5 Threshold of operation: 10 A
Location: battery compartment
63
