Protected circuits: direct battery-
powered fuel system for injection
control unit and injection loads
Fuse No. 6 Threshold of operation: 7.5 A
Location: battery compartment
Protected circuits: direct battery-
powered fuel system for instrument
panel
Fuse No. 8 Threshold of operation: 7.5 A
Location: battery compartment
Protected circuits: live power
supply for parking control ECU,
headlight solenoid, parking system
pressure sensor, horn solenoid.
Fuse No. 9 Threshold of operation: 7.5 A
Location: battery compartment
Protected circuits: live power
supply for horn and high-beam
flash.
Fuse No. 10 Threshold of operation: 7.5 A
Location: battery compartment
Protected circuits: live power
supply for stop lights and starter
relay.
Fuse No. 11 Threshold of operation: 7.5 A
Location: battery compartment
64
