CAUTION
IN THE EVENT OF MALFUNCTION OF THE BATTERY, THE ABS - ASR SYSTEM
TURNS OFF.
02_98
Each time the starter switch is turned to the "ON" position, the ABS control unit checks
the system, which is indicated by the flashing ABS warning light. This phase ends
when exceeding 5 Km/h of speed with the switching off of the warning light.
In case of error of the system, the ABS warning light remains fixed. The braking system
keeps the characteristics of a traditional system.
In this case, reduce speed and go to an Authorised Service Centre for the appro-
priate checks.
WARNING
IF THE WARNING LIGHT IS FLASHING, THE ABS SYSTEM IS NOT ACTIVE.
64
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
