From A
Injector No. 4 (+) X9 X100 To the instrument panel cable
harness (EFI (L) main relay)
EFI ECU (VSV1) X138 X254 (Fast idle) VSV1 (-)
EFI ECU (PSW) X203 X263 Accelerator sensor (PSW)
Connection to X97-X100 - X253 (Fast idle) VSV1 (+)
Connection to Z76-Z66 - Z221 Ignition coil 2 (E)
Connection to Z76-Z66 - Z220 Ignition coil 1 (E)
EFI ECU (E01) Z47 Z49 E/G ground
EFI ECU (E1) Z48 Z49 E/G ground
Connection to X35-X34 - Z140 Accelerator sensor (E2)
Connection to Z48-Z49 - Z212 Cam sensor
Connection to Z48-Z49 - Z213 Lambda probe sensor
Connection to Z76-Z66 - Z218 Ignition coil 2
Water temperature sensor H10 H20 To the instrument panel cable
harness and water tempera-
ture gauge
EFI ECU (E02) Z76 Z66 E/G ground
Connection to Z76-Z66 - Z216 Ignition coil 1
Connection to Z48-Z49 - Z190 Lambda probe sensor (-)
PORTER 1.3 16V Electrical system
ES - 177
