- Undo the screw indicated and remove the in-
spection door.
- Undo the two screws indicated.
See also
Frame central cover
Taillight assy.
License plate holder
- Remove the side fairings.
- Undo the two screws indicated on both sides of
the vehicle.
- Disconnect the license plate light connection.
See also
Side fairings
Chassis X7 250ie
CHAS - 12

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO X7 250ie and is the answer not in the manual?

PIAGGIO X7 250ie Specifications

General IconGeneral
Engine TypeSingle cylinder, 4-stroke
Displacement244 cc
Fuel SystemElectronic fuel injection
Rear SuspensionDual hydraulic shock absorbers
Rear Brake240 mm disc
Seat Height790 mm
Cooling SystemLiquid cooled
TransmissionCVT
Front SuspensionTelescopic fork
Front BrakeDisc
Max Power16.2 kW (22 hp) at 8, 250 rpm
