PIAGGIO X8 125 Workshop Manual

Flywheel cover
Removing the hub cover
- Remove the two clamps, the two couplings and
empty the cooling system.
- Remove the 4 retainers and the flywheel cover
Removing the stator
- Remove the electric terminal of the minimum oil
pressure switch.
- Remove the two Pick-Up screws and the one for
the wiring harness bracket as well as the two stator
fixing screws shown in the figure.
- Remove the stator and its wiring.
Engine X8 125-200
ENG - 118

PIAGGIO X8 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Liquid cooled
Transmission	Automatic CVT
Fuel System	Carburetor
Fuel Capacity	12 liters
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Front Brake	Disc
Front Tire	120/70-14
Rear Tire	130/70-12
Seat Height	790 mm
