LXI 7-SLOT MODULAR SWITCHING CHASSIS 60-102C
pickering
SECTION 1 - TECHNICAL SPECIFICATION
LXI 7-Slot Modular Chassis, 60-102C
pickeringtest.com
Specifications
Specifications
Chassis Backplane: 64 bit backplane, compliant
with cPCI/PXI specification.
Provides trigger, local bus
support(subject to module
support).
Chassis Capacity: 7 off 3U user slots
available.
PXI Module compatibility
The chassis is supplied with drivers for Pickering system
40 switching modules.
Switching Support: All of 3U Pickering
Interface’s PXI switching
modules. Includes (but
not limited to): All 2 and
4 slot 3U BRIC matrices,
featuring up to 2208
crosspoints.
Instrumentation support: Programmable resistor and
potentiometer modules,
RF attenuators, battery
simulators, programmable
power supplies and digital
I/O modules.
Soft Front Panel: All supported PXI modules
can be controlled through
a W3C compliant web
browser (Internet Explorer,
Firefox, Netscape and
others).
For a selection guide on the range of modules capable of
being hosted by the 60-102C chassis, please see the PXI
Module Selection Guide in the LXI Product Guide. This
is available as a download from the On-Line Catalogs
section of our website: pickeringtest.com
Power Supply
Input Voltage Range:
Input Voltage Frequency:
Input Current Rating
100 - 240 VAC
47 to 63 Hz
8 A 115 VAC or 4 A 230 VAC
Supplied with a 400 W DC output power supply with the
following capacity:
DC Output +3.3 V +5 V +12 V -12 V
Max Current 28 A 40 A 12 A 1 A
Cooling
Airflow:
Per-slot Cooling Capacity:
Fans:
Bottom intake, rear exhaust
30 W at 55 °C ambient
1 off 100 cfm fan
Acoustic Noise Emissions
Sound Pressure Level (dBA):
Sound Power (dBA):
Minimum fan speed: 41.6 dB
Maximum fan speed 47.3 dB
Minimum fan speed: 51.9 dB
Maximum fan speed 55.5 dB
Monitoring
LXI Interface Status LEDs:
Chassis Status LEDs:
Web Page Monitoring:
Power, Ready, Error, LAN,
100BaseT, 1000BaseT
Voltage rail monitoring
Chassis air temperature,
Backplane supply voltage
levels, Fan speeds.
LAN Interface
Designed to comply with the LXI Standard Version 1.4
Connector: RJ45 Connector.
Connection Speed: 1000BaseT interface
Other Connectors
Front panel Diagnostics Port on 9 pin D connector, front
panel Aux connection on USB style connector. Neither
connection is intended for normal use, see manual for
more information.
Supporting Documentation
Manuals, drivers and a copy of the short form catalog are
stored internally and are accessible through any browser
compliant with W3C standards
Mechanical Specification
Dimensions: Width: 245 mm
Height: 192 mm (with feet)
Depth: 391 mm
For rack mounting,
recommended to be
mounted in 5U to allow free
bottom intake of air.
Weight: 4.2 kg without PXI modules
