PICO Optoma EP-PK-101 - Product Overview and Components; Battery Compartment Cover; Power OnOff Switches; Status LED Indicator

2
OFF
USB Power Input Only
AV IN
FOCUS
OFF
1
5
6
7
8
9
10
432
11
12
1. Battery Cover
2. Switch Position On (Bright mode)
3. Switch Position On (STD mode)
4. Switch Position Off
5. LED Indicator
6. USB Power Inlet
7. Lens
8. Focus Dial
9. Speaker
10. AV Input Connector
11. Screw Hole for Tripod Convertor
12. Through-hole for straps
1. Couvercle des piles
2. Position du bouton On
(mode Lumineux)
3. Position du bouton On (mode STD)
4. Position du bouton Off
5. Voyant DEL
6. Prise d’alimentation USB
7. Objectif
8. Bague de mise au point
9. Haut-parleur
10. Connecteur d’entrée AV
11.
Trou de vis pour convertisseur tripode
12. Crochet pour dragonnes
