PIEPS DSP SPORT Manual Guide

Congratulations on having purchased a PIEPS DSP PRO/DSP SPORT.
The PIEPS DSP PRO/DSP SPORT is a digital 3-antenna transceiver designed to be the easiest
to use in a companion rescue. Equipped with DSP technology (Digital Signal Processing) and
a triple-antenna-search system, the PIEPS DSP PRO/DSP SPORT not only offers a maximum
circular range, but also simplies the rescue, especially in a case with multiple burials. The new
functions of the Intelligent Transmitter help to maximize support for the user in SEND-mode –
you will be found faster with your PIEPS DSP PRO/DSP SPORT!
A transceiver cannot protect you against avalanches! Obtaining the proper level
of avalanche education, and regular practicing with all avalanche rescue equipment is essential
to carry out a safe, and effective rescue. The procedures and instructions described refer solely to
specic applications in connection with PIEPS DSP PRO/DSP SPORT. The basic rules of conduct in
case of an emergency – as dened in the relevant specialist publications and in training sessions –
must be observed without fail.
DEAR WINTER SPORTS ENTHUSIAST!
7
16
15
11
10
9
8
14
13
12
1 LCD-Display (backlight)
2 Main switch
OFF-SEND-SEARCH
3 Lock
4 SCAN Button *
5 MARK Button
6 Loudspeaker
7 Direction Indicator
8 Numeric Information
9 Battery Level
10 Display “SEND”
11 Number of Burials
12 Current Sending Antenna
13 Meter-indication at SCAN *
14 Frequency measurement *
15 TX600-Mode *
16 Inclinometer *
* Only for DSP PRO
1 1
3 3
5
6 6
4 5
2 2
DSP PRO
DSP SPORT
| 06/14
22

PIEPS DSP SPORT Specifications

General

Frequency	457 kHz
Temperature Range	-20°C to +45°C
Marking function	Yes
Number of antennas	3
Multiple Burial Function	Yes
Range	50 m
Battery Life	200 h
Batteries	3 AAA
