5
PACKAGING
• 1x PIEPS PRO BT/POWDER BT
• 3x Alkaline battery (in battery compartment)
• 1x PIEPS PRO BT/POWDER BT carrying system
• 1x PIEPS hand loop
• 1x Quick Start Guide
• 1x PIEPS-Sticker
Check that the contents are complete and undamaged after unpacking. If necessary, contact
your point of sale or our support team.
FEATURES (SEE FIGURES)
STRUCTURE DEVICE
(1A) LCD display (backlight)
(1B) Slider OFF/SEND/SEARCH
(1C) Slider lock
(1D) Button MARK
(1E) Button SCAN*
(1F) Speaker
(1G) Transmit control LED
(1H) Battery compartment
STRUCTURE DISPLAY
(2A) Direction indication
(2B) Distance indication
(2C) Transmit symbol
(2D) Battery capacity/type
(2E) MARK (marking possible)
(2F) Active transmitting antenna
(2G) Number of burials (1-3)
(2H) Number of burials (4 or more)
(2J) Transmitter marked
(2K) Bluetooth® active
(2L) Inclinator mode*
(2M) TX600 mode*
(2N) SCAN mode*
(2P) Analog mode*
(2Q) Meter symbol for SCAN /analog mode*
* PIEPS PRO BT only
CARRYING SYSTEM
PIEPS recommends using the included carrying system (3A) or an approved apparel pocket. In
order to protect the beacon’s display, carry the beacon with its display facing inwards (3B). The
transmit control LED (1G) is visible in the pouch´s window (3C).
SWITCHING ON | SELF-CHECK | SEND MODE
Switching on: Move the slider lock (1C) to the left and the slider (1B) upwards into the position
SEARCH. Then release the slider lock (1C) and move the slider (1B) downwards, until it locks in
the position SEND.
The display shows firmware version, battery capacity, self-check progress (4A), self-check
result (4B), group check countdown (4C) and finally the send display with the active transmit-
ting antenna (4D).
