pigtronix ECHOLUTION 3 - MIDI CC Map

10
12 Repeats Knob
13 Time Knob
14 Mix Knob
15 LFO Speed Knob
16
Modulation
Depth Knob
17
Time Button
Special Values:
3 = Short
4 = Med
5 = Long
18
SFX Button
Special Values:
3 = Off
4 = Pong
5 = Halo
6 = Pong and Halo
19
Taps Button
Special Values:
3 = First Tap Off
4 = First Tap 1
5 = First Tap 3/4
6 = First Tap 2/3
7 = First Tap 1/2
8 = First Tap PHI
9 = Second Tap Off
10 = Second Tap 1
11 = Second Tap 3/4
12 = Second Tap 2/3
13 = Second Tap 1/2
14 = Second Tap PHI
20 = Bit Crusher
9 = Crush Off
10 = Crush On
MIDI CC Map:
Saving: Aer using other midi commands to change parameters, MIDI Preset Save Command can be
used to save a preset.
21
Bypass Button
Special Values:
3 = None
24
LFO Mod Button
Special Values:
3 = Triangle
4 = Square
5 = Saw
6 = Random
7 = Super Triangle
8 = Super Square
9 = Super Saw
10 = Super Random
25
Tap Tempo
Footswitch
27
Engage Footswitch
Special Values:
3 = Explicitly Engaged
4 = Explicitly Not Engaged
29
Jump Footswitch /
Preset 1/2
30
Freeze Footswitch /
Preset 3/4
31
Loop Open Close
(1 = open; 1 = close).
Send a momentary 1 to
CC#31 to start a loop,
then send another to
close that loop.
76
Second Tap Volume
(mapped 0-127) Second
Tap Volume: Send the
desired value (0-127) to
MIDI CC#76 to change
the volume of the
second tap.
79
Enable MIDI Clock In
(0=off; 1=on)
