Pilot RC Extra 330SC - Tail Wheel Installation

Tail wheel Installation
With the model still upside down, position the carbon tail wheel unit on its
correct location and mark on the underside of the fuselage to drill the holes
for the screws that will hold the tail wheel in place.
Screw the tail wheel unit to the fuselage using the blind nuts and bolts
provided.Attach the springs to the underside of the rudder using the metal
arm supplied.
We recommend to keep the pivot point of the tail wheel as in line with the
We recommend to keep the pivot point of the tail wheel as in line with the
hinge line as possible to assure a bind free movement of the springs.
