A
C
D E
F
GH
J
K
L
M N
O
P
P
Q
R
S S
T
U
V
WX
ARG 300 DCT CF-NC automat, ARG 330 DC CF-NC automat
A hydraulic unit
B saw blade
C saw blade tensioning
D gearbox
E motor
F fixed vice
G movable vice
H base
I arm
J control panel
K table
L chip hopper/chip bin
M cleaning brush
N fixed bar
O movable bar
P hydraulic cylinder of the vice
Q hydraulic stroke cylinder
R screw chips conveyor
S running wheels
T coolant tank with a pump
U auxiliary roller
V clamping lever
of the movable bar
W ball screw
X actuator
