Pinnacle MS01109 - Parts Introduction; Parts Description

PAGE 8
3. PARTS INTRODUCTION
Parts Description
1. Charger Socket
2. Circuit Breaker
3. Tiller Adjust Knob
4. Seat Rotate Lever
5. Armrest
6. Under-seat Storage Box
7. Width Adjustable
Armrests Knob
8. Freewheel Lever
9. Anti-tip Wheel
10. Connecting Device
11. Front Wheel Lock knob
12. Power Switch
