The Pinnacle X-GO is a four-wheeled electric mobility scooter designed for personal mobility, offering a comfortable and secure solution for various mobility requirements. This user manual, identified as MS01109, provides comprehensive instructions for its operation, maintenance, and safety.

Function Description:

The Pinnacle X-GO scooter is an electric vehicle intended for use by a single person. It is designed to assist individuals with mobility needs, allowing them to travel on pavements and pedestrian areas. The scooter features a control panel for operation, including a battery level indicator, speed dial, horn, wigwag paddle for forward/reverse, and a headlight button. It is equipped with an electromagnetic brake system for safe stopping. The scooter can be disassembled for transport and storage without the need for tools. It also includes under-seat storage and a USB charging hole for electronic devices.

Important Technical Specifications:

Dimensions (L x W x H): 1190 mm x 560 mm x 980 mm
Weight (with battery): 75.6 kg / 166.5 lbs
Weight (without battery): 52.2 kg / 115 lbs
Battery: 34AH (2 x 11.7 kg)
Controller: PG 70A
Charger: Input AC 100-240V, Output 24V, 5 Amp
Front Wheel Size: 2.80/2.50-4 x2
Rear Wheel Size: 2.80/2.50-4 x2
Motor: DC24V / 320W / 3300RPM x1PC
Brake System: Electromagnetic brakes
Control Method: By speed control lever
Max Speed Forward: 6.4 km/h / 4 mph
Slope Grade Ability: 6°
Cruising Range: 36 km / 22.5 miles (based on 20°C, 75kg driver, new fully charged battery, constant 6.4 km/h speed with 70% battery discharge)
Max User Weight: 150 kg / 330 lbs
Seat Weight: 11.9 kg
Ground Clearance: Not specified, but seat weight is 11.95 kg.
Mass of Heaviest Part: 24.79 kg (Front Section)
Turning Circle: 1370 mm
Stowage Height: 480-530 mm
Suspensions: Yes
Basket Loading Weight: Maximum 3 kg

Usage Features:

Safety Notices: Emphasizes adherence to pedestrian traffic rules, avoiding driving under the influence or when tired, and caution in low light or busy areas. It explicitly states not to carry passengers or use the scooter to haul goods beyond the specified weight limits.
Operation Practice: Users are advised to practice operating the scooter in a wide, open area at a low speed setting before using it in busy or potentially dangerous environments.
Automatic Power Shut Down: The scooter is equipped with a feature that automatically turns it off after fifty minutes of inactivity to prevent accidental battery drain.
Braking: Releasing the speed control lever activates the electromagnetic brake, bringing the scooter to a stop.
Parking: Turning the power switch to OFF and removing the key engages the electromagnetic brake, locking the scooter.
Adjustable Features:
- Armrest Width: Knobs at the back of the seat frame allow for adjustment of armrest width.
- Seat: The seat can be swiveled 45 or 90 degrees and locked into position using a seat adjustment lever. It must be returned to the forward position before driving.
- Tiller: The tiller can be adjusted to various positions to suit the driver by loosening and tightening a knob.
USB Charging: A USB charging hole is available for charging electronic devices.
Freewheel Mode: The motor can be disengaged (Neutral mode) by pulling the freewheel lever up, allowing the scooter to be pushed manually. To drive, the lever must be pushed down (Drive mode).
Battery Indicator: The tiller console features a color-coded battery indicator: green (40-100% capacity), yellow (10-30% draining charge), and red (immediate recharge necessary).
Circuit Breaker: A main circuit breaker (reset button) protects the motor and electronics from damage due to low battery voltage, excessive loads, or steep inclines.
Disassembly/Assembly: The scooter is designed for tool-free disassembly into front and rear sections, battery pack, and seat for easier transport and storage. Assistance is recommended for personal safety during these processes.

Maintenance Features:

Daily Inspections: Users are advised to perform daily checks, referring to the "DAILY CHECKING" section.
Cleaning: The scooter should be cleaned approximately once a week with a damp cloth. The battery should be cleaned with a clean cloth, and terminals with warm water if covered by white powder.
Regular Adjustments: Tiller height and seat swivel should be adjusted weekly to ensure smooth operation.
Tyre Inspection: Regular checks for wear and tear on tyres and upholstery are recommended. Tyres should be replaced when the tread groove is less than 0.5 mm to prevent slippage and longer braking distances.
Professional Servicing: An annual service is recommended for optimum performance and extended lifespan. The first inspection should be one month after purchase, followed by checks every six months.
Battery Care:
- Always fully recharge new batteries before first use and after every use.
- Charge batteries at least once a week, even if the scooter is idle, to maintain full usability.
- Avoid exposing batteries to temperatures below -10°C or above 50°C.
- Use only the Pinnacle charger and ensure charging is complete (orange LED turns green).
- Charge in a well-ventilated area, away from direct sunlight, humidity, rain, or dew.
- Do not charge in extreme temperatures (less than -10°C or higher than +50°C).
- Disconnect the charger after charging to prevent power drain.
- Replace both batteries together when needed.
Fuse Check: If the battery charger is on but no LEDs are lit, the fuse should be checked.
Cleaning Precautions: Do not splash water directly on the scooter, use petrol, solvents, or vaporizing solutions, or use wax, as these can damage the electrics or shrouds.
Storage: Store the scooter away from direct sunlight, rain, or dew. For long-term storage, fully charge the battery and disconnect the battery terminal.
Moving: Turn off the power switch before moving. Lift the scooter by the chassis, not the bumpers, and seek assistance if needed.
