Operator's Manual FM-1700, 2000 29
HANDLE ASSEMBLY
Item Ref. No. Qty Description
1 445178 1 Label-Inter Lock
2 500241 2 Adapter Switch FM
3 502040 1 Clamp, Handle Tube
4 504540 1 Hook Cord FM
5 505140 2 Lever Switch FM
6 508340 2 Spring-Switch Lever FM
7 627561 1 Strain-Relief
8 911690 2 Switch FM1500-2300 Mp18 Cline
9 962015 2 Screw 10-24 X 3/8 Pn St Ph
10 962241 2 Screw, 10-24 X 1/2
11 962289 5 Screw, 1/4-20 X 3/4
12 962391 1 Screw 10-24x1 Sc St Cap
13 22109A 1 Cover, Switch Housing
14 24507A 1 Housing Handle/Switch FM 150
15 24508A 1 Housing-Switch Front
16 34612B 1 Griphandle Left Gp-18
17 34613B 1 Grip Handle Right Gp-18
18 38004A 1 Stop-Switch Interlock
19 41925A 1 Cord-Interconnecting handle
20 61120A 1 Bracket-Switch Stop
21 67900A 1 Spring-Switch Lever
22 68318A 1 Tube, Handle
23 80290A 1 Screw 10-32 X .38 HRCS
24 80291A 1 Washer, Flat #10 (.203x.734x.063)
25 83003A 4 Rivet 1/8 X 3/8
26 84807A 2 Screw 6-32 X 1 5/8 Pan Hd
