Amano Pioneer Eclipse
�
Operator's Manual FM-1700, 2000 31
BASE ASSEMBLY
Item Ref. No. Qty Description
1# 167308 2 Ringretaining-External .500 NOTE 1
2 170667 2 Wire Connector Twist On 74b
3 318303 1 Spring, Bearing Load
4 500342 1 Arm Adjusting Weldt
5 501141 2 Bushing, Link Arm
6 501142 2 Bushing FM
7 501345 1 Plug Button 25/32 FM
8 501346 1 Bolt-Locking Cam FM
9# 501540 2 Cap Hub FM NOTE 1
10 502304 1 FM17 Cover Capacitor
11 502342 1 Cover, Main Hsg. Bott.
12 502402 1 FM17 Capacitor 115v
13 502403 2 FM17 Cushion Capacitor
14 503542 1 Gear Unit Asm, FM
15 504740 1 Insulator Elbow FM
16 506740 1 Pin Handle Pivot FM
17 506842 1 Plug FM
18 507572 1 Motor Relay-FM 1hp
19# 507741 1 Shaft Wheel FM NOTE 1
20 509240 1 Tongue, Handle Tube
21 509806 1 Wiring Diagram FM-15-17
22 743850 1 Guide Handle Lock Cm-20
23 857557 1 Strain Relief Ro42
24 902550 1 Bearing Ball-6203
25 920110 1 Nut, 5/16-18 Hex Lock
26 920349 1 Nutstopelastic1/4-20 Hvythn
27 920365 1 Nut 1/2-13 Nylock
28 960969 1 Bolt Shoulder 5/16 X 3/4
29 962233 2 Scr 1/4 -20x 5/16 St St Knurl
30 962330 1 Screw, 6-32 X 3/8 Pan Hd.
31 962337 5 Screw 1/4-20 X 1/2 Sc St Cap
32 962727 3 Screw, 8-32 X 1/2
Item Ref. No. Qty Description
33# 962823 2 Screw, 1/4-20 X 1/2 P.H. NOTE 1
34 962826 6 Screw 10-24x 3/8 Pn St Tp F Ph
35 962892 8 Screw 1/4-20 Unc X 3/4 Pan Head
36# 980215 6 Washer, Thrust NOTE 1
37 980603 4 Washer, #10 Lock External Tooth
38 980614 8 Washer, 1/4” Starlock, External
39 980648 1 Washer 17/32 X 1 1/16 Plain
40 980652 2 Washer, 5/16 Lock
41 980675 1 Wash-.190idx.406od Ex Th
42 22105A 1 Covermain HousingFM
43 22106A 1 Cover, Drip
44 24502C 1 Housing-Main FM1500-2000
45 31237B 1 Bumper Main Hsg.
46 40254A 1 Harness Wire
47 40658A 1 Field And Rotor Kit
48# 59961A 2 Wheel Asmgray FM/GP-18 NOTE 2
49 61912A 1 Handle Cam Lock
50 66636A 1 Plate-Strain Relief
51 77195A 1 Label-Ul Fire & Sand.
52 85310A 4 Screw10-24 X 2 Pan Hd
53 85812A 1 Screw5/16-18 X 7/8 Hex Hd Gr5
54 85817A 1 Screw 5/16-18 X 2.00 Hex Hd Gr5
* 501440 1 Cam Asm Locking FM (includes 8, 26, 28, 49)
55# 56384051 1 Shaft-Wheel-10.99 x Ø0.50
56# 56384052 2 Wheel--5.00 x 2.00
57# 87058A 2 Washer, Retainer
58# 56109766 2 Screw Button Head 1/4-20 X .63
* = Optional, Not Included
# = Revised or new since last update
NOTE 1: This part is still available for replacement purposes but a new wheel kit can be ordered to replace both wheels and their
mounting hardware (FM Polisher Wheel Kit is 56384053).
NOTE 2: Wheel Assembly 59961A is obsolete please order FM Polisher Wheel Kit 56384053 for replacement.
