Pioneer Eclipse PE225FP - Page 17

17
Main Assembly (continued)
Item Ref. No. Description Qty
1 21075A BACK, HANDLE 1
2 10687A MODULE, INTERLOCK 1
3 21074A FRONT, HANDLE 1
4 MP499200 DECAL, PE225FP, HANDLE 1
5 80284A SCREW, #10 X 3/4” 6
6 61373A TUBE, HANDLE 1
7A MP476300 CORD, POWER, 14/3 X 50FT 1
7B 486500 CORD, POWER, TYPE I, 50FT 1
8 50781A CLAMP, HANDLE 1
9 40789A CORD, INTERCONNECT 1
10 56109699 CAM, w/ GRIP, ASM. 1
11 80291A WASHER, FLAT, #10 1
12 980349 WASHER, WEAR 1
13 920342 NUT, HEX, 3/8” 1
14 980673 WASHER, FLAT, 1/2” 2
15 80290A SCREW, #10 X 3/8” 6
16 80292A SCREW, 1/4” X 1” 2
17 39857A WHEEL, 5” 2
18 980648 WASHER, 17/32” X 1-1/16” 2
19 80295A WASHER, BOWED 2
20 61741A ARM, LINK, RIGHT 1
21 61725A AXLE 1
22 61740A ARM, LINK, LEFT 1
Item Ref. No. Description Qty
23A 53650A MOTOR, GEARBOX (120V) 1
23B 53652A MOTOR, GEARBOX (230V) 1
23C AS001900 MOTOR, GEARBOX, 120V, 2SPD 1
24 61716A COVER, DRIP, MOTOR 1
25 21088A FRAME, MAIN 1
26A MP481100 DRIVER, PAD, 16” 1
26B MP478400 DRIVER, PAD, 19” 1
27A 11006A SHROUD, 17”, ASM. 1
- 61715A SHROUD, 17” 1
- 30381A BUMPER, 17” 1
27B MP478000 SHROUD, 20”, ASM. 1
- MP473200 SHROUD, 20” 1
- MP478100 BUMPER, 20” 1
28 80294A SCREW, SH, 5/16” X 1-5/8” 4
29 53833A PIN, 1/2” X 2” 2
30 980603 WASHER, EXT TOOTH, #10 2
31 NB021600 CLAMP, 3/8” 1
32 A0001-BLK4 TANK, 2-1/2 GAL, ASM. 1
33 NB6035 TIE, CABLE, 1/8” X 4”, BLK 2
34 MP473700 COUPLING, FEMALE, 3/8” 1
35 MP473800 COUPLING, MALE, 1/4” 1
36 NB064900 SCREW, #10 X 1/2” 1
37 MP473900 TUBING, PVC, 1/4” ID 12”
38 MP498300
DECAL, APEC, 3” (ON MOTOR)
(NOT SHOWN)
1
