Pioneer Eclipse PE225FP - Page 23

23
HANDLE ASSEMBLY - 225FP17EB AND 225FP20EB MODELS
Item Ref. No. Description Qty
1 50780A HANDLE, REAR, C2K 1
2 30285A HANDLE FRONT C2K W/BLANK 1
3 50798A LEVER, SWITCH, C2K 2
4 50806A BUTTON, INTERLOCK, C2K 1
5 50799A INTERLOCK, MAIN, C2K 1
6 40109A SWITCH, MINIATURE-SPNO, C2K 2
7 50821A SPRING, COMPRESSION, C2K 1
8 50820A SPRING, EXTENSION, C2K 2
9 85383A SCREW 10-32 X 3/4 PAN HD 6
10 920722 BUT, 10-32 ELASTIC STOP ZN. PL. 7
11 962957 SCREW, 10-16 X 1/2 HI-LO 2
12 50930A CORD RETAINER, C2K 1
13 77094A LABEL, GROUND SYMBOL 1
14 170686 NUTLK FOR 1/2 CONDUIT 1
15 AS006800 DECAL “N” 1
16 80290A SCREW, 10-32 UNF X .375 1
17 MP506300 CORD, POWER SUPPLY, BRAZIL (EB) 1
17 AS018800 CORD, POWER SUPPLY, CE (E) 1
18 AS017400 HANDLE, TUBE, WELDMENT 1
19 AS018000 CORD, INTERCONNECT, EXPORT 1
20 50781A CLAMP HANDLE C2K 1
21 MP500900
DECAL, PE225FP, HANDLE,
EXPORT (NOT SHOWN)
1
RF066700
