Deck Assembly (continued)
31
Item Ref. No. Description Qty
1A MP107700 SPINDLE, 6.75”, ASM. (21”) 1
1B MP447700 SPINDLE, 9.25”, ASM. (28”) 1
2 MP197100 SHIM, 1/32” 1
3 MP197000 SHIM, 1/16” 1
4 NB6864 BOLT, HEX, 1/2” X 1-1/4” 4
5 NB9269 WASHER, FLAT, 7/16” 4
6 MP012801 CASTER, 2-1/2” 1
7 MP071800 TENSIONER, BELT 1
8 NB6044 BOLT, HEX, 3/8” X 1-1/4” 1
9 NB3450 WASHER, FLAT, 3/8” 1
10 NB003100 NUT, LOCK, 1/2” 1
11 MP366001 BRACKET, WHEEL 2
12 MP105300 WHEEL, 5” 2
13 MP038100 PIN, CLEVIS, 3/8” X 2-1/8” 2
14 LX2105 CLIP, HITCH PIN 2
15 NB6545 BOLT, HEX, 5/16” X 1” 4
16 NB3265 NUT, LOCK, 5/16” 4
17 NB028200 WASHER, FLAT, 5/8” 4
