Main Assembly (continued)
35
Item Ref. No. Description Qty
1 NB5520 BOLT, HEX, 1/4” X 1” 2
2 MP105900 CYLINDER, STEEL, LP 1
3 NB064900 SCREW, #10 X 1/2” 1
4 MP368200 REGULATOR, ASM. 1
5 NB065100 BOLT, HEX, M8 X 25 1
6A MP272900 BELT, BX-57 (28”) 1
6B MP8070 BELT, BX-46 (21”) 1
7 MP195300 SPACER, BEARING 1
8A MP351200 PADHOLDER, 28” 1
8B MP269400 PADHOLDER, 21” 1
8C MP012700 RETAINER, PAD (NOT SHOWN) 1
9 NB6044 BOLT, HEX, 3/8” X 1-1/4” 3
10 MX1075 WASHER, LOCK, 3/8” 3
11 NB5520 BOLT, CARRIAGE, 3/8” X 1-1/4” 3
12 NB3267 NUT, LOCK, 3/8” 3
13 NB019100 BOLT, HEX, 1/4” X 3/4” 2
14 NB6110 WASHER, LOCK, 1/4” 2
15 NB3350 WASHER, FLAT, 1/4” 7
16 NB6545 BOLT, HEX, 5/16” X 1” 6
17 NB9267 WASHER, FLAT, 5/16” 8
18 NB3265 NUT, LOCK, 5/16” 4
19 MP367500
TRAY, BATTERY
1
20 NB8125
CLAMP, 1/4”
1
21 MP362200
BATTERY, 12V
1
22 MP368100
STRAP, 2” X 23”
3
23 N/A
N/A
1
24 NB3450
WASHER, FLAT, 3/8”
6
25 NB3275
NUT, LOCK, 1/4”
2
26 NB6111
WASHER, LOCK, 5/16”
3
27 MP6600
FELT, BLACK
12”
28 MP6600
FELT, BLACK
15”
To Next Page
