Specifications
General
Power source ................... 14.4 V DC (12.0 V to 14.4 V al-
lowable)
Grounding system ............ Negative type
Maximum current consum ption
................................... 10.0 A
Dimensions (W × H × D):
D
Chassis .............. 178 mm × 100mm ×
165 mm
Nose .................. 171mm × 97 mm ×
18 mm
(AVH-X5550BT/AVH-X4550DVD)
Nose .................. 171mm × 97 mm × 9mm
(AVH-X2550BT/AVH-X1550DVD)
Weight ............................. 2.0kg
(AVH-X5550BT/AVH-X4550DVD)
Weight ............................. 1.7 kg
(AVH-X2550BT/AVH-X1550DVD)
Display
Screen size/aspect ratio ... 6.95 inch wide/16:9
(effective display area:
156.6 mm × 81.6 mm)
(AVH-X5550BT/AVH-X4550DVD)
Screen size/aspect ratio ... 6.1 inch wide/16:9
(effective display area:
136.2 mm × 72.0 mm)
(AVH-X2550BT/AVH-X1550DVD)
Pixels ............................... 1 152000 (2400 × 480)
Display method ................ TFTactive matrix, driving type
Color system .................... NTSC/PAL/PAL-M/PAL-N/
SECAM compatible
Durable temperature range (power off)
................................... –20 °C to +80 °C
Audio
Maximum power output ... 50 W × 4
70 W × 1/2 W (for subwoofer)
Continuous power output
................................... 22 W × 4 (50Hz to 15 000 Hz,
5 % THD, 4 W load, both chan-
nels driven)
Load impedance .............. 4 W (4 W to 8 W (2 W for 1 ch)
allowable)
Preout maximum output level
................................... 4.0V
(AVH-X5550BT/AVH-X4550DVD)
Preout maximum output level
................................... 2.0V
(AVH-X2550BT/AVH-X1550DVD)
Equalizer (8-Band Graphic Equalizer):
Frequency ................. 40Hz/80 Hz/200 Hz/400 Hz/
1 kHz/2.5 kHz/8 kHz/10 kHz
Gain ......................... ±12dB
HPF:
Frequency ................. 50Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope ........................ –12 dB/oct
Subwoofer (mono):
Frequency ................. 50Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope ........................ –18 dB/oct
Gain ......................... +6 dB to –24 dB
Phase ....................... Normal/Reverse
Bass boost:
Gain ......................... +12 dB to 0 dB
DVD Player
System ............................ DVD video, Video CD, CD,
WMA, MP3, AAC, DivX, JPEG,
MPEG player
Usable discs .................... DVD video, Video CD, CD, CD-
R/RW, DVD-R/RW/R DL
Region number ................ 3
Frequency response ......... 5 Hz to 44000 Hz (with DVD,
at sampling frequency 96 kHz)
Signal-to-noise ratio ......... 96dB (1kHz) (IEC-A network)
(RCA level)
Output level:
Video ........................ 1.0 Vp-p/75 W (±0.2 V)
Number of channels ........ 2 (stereo)
MP3 decoding format ...... MPEG-1 & 2 Audio Layer 3
WMA decoding format ..... Ver. 7, 7.1, 8, 9, 10, 11, 12 (2ch
audio)
(Windows Media Player)
AAC decoding format ....... MPEG-4 AAC (iTunes enco ded
only) (.m4a)
(Ver. 10.6 and earlier)
JPEG:
JPEG decoding format
............................ .jpeg, .jpg, .jpe
Pixel Sampling .......... 4:2:2, 4:2:0
Decode Size .............. MAX:8 192(H) x 7 680(W),
MIN:32(H) x 32(W)
DivX decoding format ....... Home Theater Ver. 3, 4, 5.2, 6
(Except ultra and HD) (.avi,
.divx)
MPEG video decoding format
................................... MPEG1, MPEG2, MPEG4
USB
USB standard specification
................................... USB 1.1, USB 2.0 full speed
(For video files)
USB 2.0 high speed (For
audio files)
Maximum current supply
................................... 1.0A
USB Class ....................... MSC (Mass Storage Class)
File system ....................... FAT16, FAT32
MP3 decoding format ...... MPEG-1 & 2 Audio Layer 3
WMA decoding format ..... Ver. 7, 7.1, 8, 9, 10, 11, 12 (2ch
audio)
(Windows Media Player)
AAC decoding format ....... MPEG-4 AAC (iTunes enco ded
only)
(Ver. 10.6 and earlier)
WAV:
WAV signal format .... Linear PCM, MS ADPCM
(.wav)
Sampling Frequency
............................ Linear PCM:16 kHz,
22.05 kHz, 24 kHz, 32 kHz,
44.1 kHz, 48 kHz
MS ADPCM:22.05 kHz,
44.1 kHz
JPEG:
JPEG decoding format
............................ .jpeg, .jpg, .jpe
Pixel Sampling .......... 4:2:2, 4:2:0
Decode Size .............. MAX:8 192(H) x 7 680(W),
MIN:32(H) x 32(W)
DivX decoding format ....... Home Theater Ver. 3, 4, 5.2, 6
(Except ultra and HD) (.avi,
.divx)
MPEG video decoding format
................................... MPEG1, MPEG2, MPEG4
FM tuner
Frequency range .............. 87.5 MHz to 108.0 MHz
Usable sensitivity ............. 9 dBf (0.8 µV/75 W, mono, S/N:
30 dB)
Signal-to-noise ratio ......... 72dB (IEC-A network)
AM tuner
Frequency range .............. 530 kHz to 1 640kHz (10 kHz)
531 kHz to 1 602 kHz (9 kHz)
Usable sensitivity ............. 25 µV (S/N: 20 dB)
Signal-to-noise ratio ......... 62dB (IEC-A network)
Bluetooth
(AVH-X5550BT/AVH-X2550BT)
Version ............................ Bluetooth 3.0 certified
Output power ................... +4dBm Maximum
(Power class 2)
Note
Specifications and the design are subject to
modifications without notice.
