Pioneer D514 User Manual

Additional information
09
45
En
Miscellaneous
Power Requirements ................ AC 120 V, 60 Hz
Power Consumption ................................. 260 W
In Standby ................................................... 0.5 W
AC Outlet .................. 100 W MAX. (SWITCHED)
Dimensions
.......................... 420 (W) x 158 (H) x 393 (D) mm
(16-9/16 (W) x 6-1/4 (H) x 15-1/2 (D) in.)
Weight (without package) ......................... 9.3 kg
(20.5 lb)
Furnished Parts
AM loop antenna ................................................ 1
FM wire antenna ................................................ 1
Dry cell batteries (AA size IEC R6) ................... 2
Remote control ................................................... 1
Operating instructions ...................................... 1
Warranty Card .................................................... 1
Specifications and the design are subject to
possible modifications without notice, due to
improvements.
* Measured pursuant to the Federal Trade
Commission’s Trade Regulation rule on Power
Output Claims for Amplifiers.
** Measured by Audio Spectrum Analyzer.
Video Section
Input (Sensitivity/Impedance)
DVR/VCR, DVD/LD, TV/SAT ............. 1 Vp-p/75 Ω
Output (Level/Impedance)
DVR/VCR ........................................... 1 Vp-p/75 Ω
Frequency Response
DVR/VCR, DVD/LD,
TV/SAT ] MONITOR ........... 5 Hz to 7 MHz dB
Signal-to-Noise Ratio ................................. 55 dB
Cross Talk .................................................... 55 dB
FM Tuner Section
Frequency Range ............. 87.5 MHz to 108 MHz
Usable Sensitivity ................ Mono:13.2 dBf, IHF
(1.3 µV/ 75 Ω)
50 dB Quieting Sensitivity .......... Mono: 20.2 dB
Stereo: 38.6 dBf
Signal-to-Noise Ratio ..................... Mono: 73 dB
(at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Distortion ........................... Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity .................... 60 dB
(400 kHz)
Stereo Separation ......................... 40 dB (1 kHz)
Frequency Response .................. 30 Hz to 15 kHz
(±1 dB)
Antenna Input (DIN) .............. 75 Ω unbalanced
AM Tuner Section
Frequency Range .............. 530 kHz to 1,700 kHz
Sensitivity (IHF, Loop antenna) ............ 350 µV/m
Signal-to-Noise Ratio ................................. 50 dB
Antenna ........................................ Loop antenna
+0
– 3
XRE3077A.En.41.48 03.12.12, 3:37 PM45

Pioneer D514 Specifications

General

Total harmonic distortion	0.08%
Frequency response	10 Hz - 100 kHz
Speaker load impedance	4 - 16 Ω
Dimensions (mm)	420 x 140 x 352.5mm
Tuning range	FM, MW
