Pioneer DEH-X6500BT Service Manual

DEH-X65BT/XNUC
3
5 678
56
7
8
C
D
F
A
B
E
Laser diode characteristics
Wave length : 785 nm to 814 nm
Maximum output : 1 190 µW(Emitting period : unlimited)
Additional Laser Caution
Transistors Q101 in PCB drive the laser diodes.
When Q101 is shorted between their terminals, the laser diodes will radiate beam.
If the top cover is removed with no disc loaded while such short-circuit is continued,
the naked eyes may be exposed to the laser beam.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacturer.
Discord used batteries according to the manufacturer's instructions.

Pioneer DEH-X6500BT Specifications

General

MP3 playback	Yes
Preset stations quantity	24
Product color	Black
Volume control	Rotary
Disc types supported	CD, CD-R, CD-RW
Equalizer bands quantity	5
Display type	LCD
Display number of colors	210000 colors
USB version	2.0
Bluetooth profiles	A2DP, AVRCP, HFP, SSP
Line outputs (RCA)	2
USB ports quantity	1
Handheld remote control	No
Amplifier output power	200 W
