DEH-X65BT/XNUC
67
12. ELECTRICAL PARTS LIST
NOTE:
Parts whose parts numbers are omitted are subject to being not supplied.
The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding
PC board.
IC 301 (A, 91, 111) IC NJM2068V
The expression of the unit in this manual is shown by u instead of µ. Please do not make a mistake.
Circuit Symbol and No. Part No.
A:DEH-X65BT/XNUC
B:DEH-X6500BT/XNUC
C:DEH-X5500BT/XNEW5
D:DEH-X6550BT/XNES
E:DEH-X6590BT/XNID
Unit Number : QWM3432(A)
Unit Number : QWM3431(B)
Unit Number : QWM3430(C)
Unit Number : QWM3433(D)
Unit Number : QWM3434(E)
Unit Name : Tuner Amp Unit
Unit Number :
Unit Name : Keyboard Unit
Unit Number : QWM3533
Unit Name : BT Unit
Unit Number : CWX4023
Unit Name : CD Core Unit (S11.6STD)
A
Unit Number : QWM3432(A)
Unit Number : QWM3431(B)
Unit Number : QWM3430(C)
Unit Number : QWM3433(D)
Unit Number : QWM3434(E)
Unit Name : Tuner Amp Unit
MISCELLANEOUS
IC 201 (A,101,107) LSI PM9013A
IC 301 (A,78,142) IC PA2030A
IC 401 (A,150,91) IC TDA7706
IC 531 (A,93,88) IC 337S3959
IC 551 (A,19,111) IC BD9876EFJ
IC 552 (A,106,24) IC BD2232G-G
IC 601 (A,110,77) IC R5S726A0D216FP
IC 671 (A,131,75) IC S-80827CNMC-B8M
IC 681 (A,114,94) Flash ROM Unit(A,B) PEB040A8
(A,114,94) Flash ROM Unit(C,D,E) PEB039A8
IC 801 (A,104,18) L-MOS And Gate TC7SET08FUS1
IC 911 (A,145,28) IC BA49183-V12
IC 961 (A,131,110) IC TPD1052F
Q 251 (A,13,130) Chip Transistor RN1910
Q 252 (A,23,131) Chip Transistor RN1910
Q 301 (A,87,125) Chip Transistor RN4983
Q 302 (A,127,104) Transistor LTC014YEB
Q 531 (A,93,97) Transistor LSAR523UB
Q 601 (A,93,68) Transistor LTC014YEB
Q 751 (A,142,139) Transistor 2SD2396
Q 752 (A,142,133) Chip Transistor RN4983
Q 871 (A,144,59) Transistor 2SA1577
Q 872 (A,144,67) Transistor LTC143EUB
Q 941 (A,96,121) Transistor LSCR523UB
D 301 (A,102,125) Diode CRG03
D 302 (A,90,121) Diode CRG03
D 401 (A,158,107) Diode RN731VN
D 402 (A,158,100) Diode RN731VN
D 551 (A,22,124) Diode CMS03
D 552 (A,22,104) Diode RB056L-40
D 751 (A,138,135) Diode RKZ8.2KG(B2)
D 801 (A,105,15) Diode DZ2S068C
D 802 (A,92,17) Diode DZ2S068C
D 803 (A,126,15) Diode DZ2S068C
D 804 (A,119,14) Diode DZ2S068C
D 805 (A,120,14) Diode DZ2S068C
D 806 (A,116,13) Diode DZ2S068C
D 807 (A,113,13) Diode DZ2S068C
D 808 (A,117,13) Diode DZ2S068C
D 809 (A,112,13) Diode DZ2S068C
D 901 (A,141,127) Diode 1SR154-400
D 902 (A,137,127) Diode 1SR154-400
Circuit Symbol and No. Part No.
